Pro Ecosystem Pond Kit w/ Submersible Pump, 7' Falls, 4200 gph
The pro level ecosystem pond kit includes all our best equipment recommendations in one convenient package. The kit on this page is designed to pump 4200 gallons per hour.
Size of pond for the 4200 gph kit:
- Fish Pond - up to 4200 gallons of water in the pond for pumping the entire contents of the pond each hour.
- No Fish in Pond - up to 8400 gallons of water max in the pond for pumping the entire pond every one to two hours.
You do not have to purchase all items in the kit, you set quantity to 0 below if there is an item you do not want to purchase.
Add to Cart to see Total Price
Specs
- Flow Rate: 4200 gph
- Pump: Submersible
- Waterfall Height: 7 Feet
- Waterfall Width: 44" (2 separate waterfall spillway units at 22" each)
- Pond Size: Fish ponds up to 4200 gallons, and non-fish ponds up to 8400 gallons.
- Example Pond Size:
- Includes Liner? No
- Includes Waterfall Spillway? Yes
- Head Pressure: 24’ with 2” pipe, 50’, 7’ high waterfall, UV (3" pipe would save about 4' of head)
This kit does not include a liner. We recommend our Premium Grade RPE Laminated Liner for free-form shapes, or our Rectangular Box-Welded Liners for formal rectangular shapes.
Order of Water Flow / Installation
- Water enters skimmer
- Water enters pump inside skimmer. Pump has 2" threaded outlet
- Connects to check valve with 2" slip outlet
- Short piece of 2" PVC pipe to connect check valve to PVC adapter
- PVC adapter 2" Slip to 2" MPT threaded
- 2" bulkhead fitting that comes with helix skimmer
- PVC adapter 2" MPT to 2" slip that comes with skimmer
- 2" pipe from skimmer to filter
- Filter with 2" inlet/outlet
- 2" pipe run from filter to uv clarifier
- Filter with 2" inlet/outlet
- 2" pipe to wye fitting
- Wye fitting to convert single pipe to 2 separate pipes - one for each waterfall spillway
- (quantity 2 - one for each waterfall spillway) PVC fitting 2" slip to 2" MPT
- (quantity 2 - one for each waterfall spillway) 2" Threaded inlet into waterfall units
Included Fittings in Kit: (3) 2" Slip x 2" MPT, (1) Bulkhead Fitting 2" (comes with skimmer), (1) 2" Slip x 2" MPT (comes with skimmer), (1) 2" Wye Fitting
SKU | KIT-ECO-SP-7f-4200 |
---|
